C13770-50Uは、科学計測用CMOSイメージセンサを搭載し、低ノイズ・高解像度・高速読み出しを同時に実現したカメラです。コンパクトなボード型カメラのため、装置組み込みをはじめとする幅広い用途に対応します。 インターフェースは、USB 3.0です。 また、お客様のご要望に合わせたカスタマイズにも対応いたします。詳しくは弊社までお問い合わせください。
|有効画素数||2464 (H) × 2056 (V)|
|画素サイズ||3.45 μm (H) × 3.45 μm (V)|
|有効素子サイズ||8.50 mm (H) × 7.09 mm (V)|
|飽和電荷量||10 500 electrons (typ.)|
|読み出し速度||40 フレーム/秒 （全画素読み出し）
134 フレーム/秒 （2×2ビニング）
3406 フレーム/秒 （2×2ビニング、4ライン サブアレイ）
|露光時間||20.71 μs～1 s （内部同期モード）
20.71 μs～1 s（外部トリガモード：エッジトリガ、スタートトリガ）
1 ms～1 s（外部トリガモード：レベルトリガ、読み出し同期トリガ）
|ダイナミックレンジ||4565 : 1 *1|
|トリガ遅延機能||0 s ～ 10 s（1 μs ステップ）|
|コネクタ仕様||USB 3.0 microB type|
|電源||Bus Power/DC+8 V～DC+30 V|
|動作周囲温度||0 ℃ ～ ＋40 ℃|
|保存周囲温度||－10 ℃ ～ ＋50 ℃|
|動作周囲湿度||30 %～80 %（結露しないこと）|
|保存周囲湿度||90 % 以下（結露しないこと）|
