|有効画素数||2048 (H) × 1544 (V)|
|画素サイズ||3.45 μm (H) × 3.45 μm (V)|
|有効素子サイズ||7.06 mm (H) × 5.32 mm (V)|
|飽和電荷量||10 500 electrons (typ.)|
|読み出し速度||65 フレーム/秒 （全画素読み出し）
206 フレーム/秒 （2×2ビニング）
3981 フレーム/秒 （2×2ビニング、4ライン サブアレイ）
|読み出しノイズ||2.3 electrons（rms） typ.（アナログゲイン1倍）|
|露光時間||19.70 μs～1 s （内部同期モード）
19.70 μs～1 s（外部トリガモード：エッジトリガ、スタートトリガ）
1 ms～1 s（外部トリガモード：レベルトリガ、読み出し同期トリガ）
|ダイナミックレンジ||4565 : 1 *1|
|トリガ遅延機能||0 s ～ 10 s（1 μs ステップ）|
|コネクタ仕様||USB 3.0 microB type|
|電源||Bus Power/DC+8 V～DC+30 V|
|動作周囲温度||0 ℃ ～ ＋40 ℃|
|保存周囲温度||－10 ℃ ～ ＋50 ℃|
|動作周囲湿度||30 %～80 %（結露しないこと）|
|保存周囲湿度||90 % 以下（結露しないこと）|
