|画素サイズ||12 μm(H)×12 μm(V)|
|有効撮像エリア||24.58 mm(H)×1.536 mm(V)|
|TDI出力チャンネル||4 TAP (512×128)|
|TDIラインレート||0.45 kHz～50 kHz|
|飽和電荷量||80 000 electrons（typ.）|
|読み出しノイズ||50 electrons rms （typ.）|
|A/Dコンバータ||12 bit/8 bit③（typ.）|
|インターフェース||Camera Link Base Configuration|
|カメラコントロール||Camera Link (シリアルコマンドラインを使用)|
|カメラ出力チャンネル||2 TAP (1024 × 128)|
|コネクタ仕様||Mini-Camera Link (SDR) × 1|
|動作周囲温度||0 ℃～+40 ℃|
|保存周囲温度||-10 ℃～+50 ℃|
|動作･保存周囲湿度||90 ％ (ただし結露しないこと)|
|動作周囲湿度||0 ％～80 ％ (ただし結露しないこと)|
