|画素サイズ||12 μm(H)×12 μm(V)|
|有効撮像エリア||24.58 mm(H)×1.536 mm(V)|
|TDIラインレート||0.457 kHz～50 kHz|
|飽和電荷量||80 000 electrons （typ.）|
|読み出しノイズ||50 electrons rms （typ.）|
|アナログゲイン||1 倍～5 倍（16段階）|
|A/Dコンバータ||12 bit/8 bit③|
|インターフェース||Camera Link base configuration|
|コネクタ仕様||Mini-Camera Link (SDR)×1|
|電源||AC100 V～AC240 V、50 Hz/60 Hz|
|動作周囲温度||0 ℃～+40 ℃|
|保存周囲温度||-10 ℃～+50 ℃|
|動作･保存周囲湿度||90 ％ (ただし結露しないこと)|
|動作周囲湿度||30 %～70 ％ (ただし結露しないこと)|
