The C10000-801 TDI camera is useful for a wide range of imaging applications requiring high speed operation with high sensitivity simultaneously. Also, frame readout mode is available for easy focusing.
|Imaging device||Back thinned type|
|Effective number of pixels||2048 (H)×128 (V)|
|Cell size||12 μm (H)×12 μm (V)|
|Effective area||24.58 mm (H)×1.536 mm (V)|
|Readout mode||TDI readout mode / frame readout mode*1|
|TDI transfer direction||Bidirectional transfer|
|TDI output channel||4 TAP (512×128)|
|Anti-blooming||Yes (100 times of the full well capacity)|
|TDI pixel clock rate||30 MHz|
|TDI line rate||0.457 kHz to 50 kHz|
|TDI line rate control||Internal setting by serial command*2 / External trigger|
|Full well capacity||80 000 electrons (typ.)|
|Readout noise||50 electrons rms (typ.)|
|Analog gain||1 time to 5 times (16 steps)|
|A/D converter||12 bit/8 bit*3|
|Image processing||Real-time shading correction / Back ground subtraction|
|Interface||Camera Link base configuration|
|Camera control||Serial control in Camera Link|
|Camera output clock||60 MHz|
|Camera output channel||2 TAP (1024×128)|
|Connector||Mini-Camera Link (SDR)×1|
|Power requirements||AC100 V to AC240 V, 50 Hz/60 Hz|
|Power consumption||Approx. 55 VA|
|Ambient operating temperature||0 ℃ to +40 ℃|
|Ambient storage temperature||-10 ℃ to +50 ℃|
|Ambient operating/storage humidity||90 % or less (with no condensation)|
|Ambient operating humidity||30 % to 70 % (with no condensation)|
